Maintenance and fault handling of batching weighting silo in dry mortar production line

Batching weighting silo plays a very important role in the dry mortar production line. Batching scale refers to the weighing instrument for batching several substances in the said substance given mass share in advance. Therefore, the precision of batching scale is directly related to the production quality of goods, and strict attention is needed in production. Zhengzhou Yishang Machinery Equipment Co., Ltd. is one of its own dry mortar equipment manufacturers, for dry mortar equipment has rich experience in research and development, the following we will introduce in detail the daily use and maintenance of the dry mortar production line of mixing scale, and how to deal with the failure.

1. Do not turn off the power when there is material in the weighing hopper.


2. The hopper must be emptied when the power needs to be turned off after work.

3. Each feeding shall be 1000KG or less

4. Add diesel oil to the reducer and change the oil every three months. Check the oil window every three days and fill it in time.


Troubleshooting:

1. Check the motor, remove the motor, check whether the key is worn, whether the shaft is broken

2. Drop the spiral blade and check the whole body.

3. said bucket measurement is not accurate, one, check whether the sensor wiring is damaged, two, standing in the ingredients said bucket corresponding to the three sensors above, see whether the weight of the three corners of the display is too big, the difference of the sensor and other swap or change the difference of the sensor.
