Automatic dry mortar bags palletizer

This set bags packing line is our company provide for your Bosnia and Herzegovina clients ,Total line length is 7.5m, width is 2.5m ,height is 3.8m. include two set air floating packing machine  horizontal belt conveyor  slant belt conveyor  column type palletizer . This line capacity is 500-550bags per hour ,per times worker can place two set pallet on bottom base , machine can stack left and then right , can achieve continue to work .

Column type palletizer is easy to  mantain and repair , can change program refer to clients bags and pallet . Our belt conveyor adopt to interior inseted type motor ,motor is durable and long life,and belt adopt to resistant wear materials ,using life is 5-6 years .

About maintenance of palletizer ,palletizer have two section slideway , should fill liquid oil on per days , we have design fill oil hole for clients and have symbol  on every hole . bottom base and lift chain strip should fill grease , we have reveal these information on maintenance booklet. top and beam gearbox should replaced per three month .

Intelligent PLC control system help you to be easy control palletizer .
