Equipment model:

YS-50A

Measurement structure:

Powder gross weight measurement structure

Feeding mode:

Air-flow feed control structure

Packing bag:

Valve pocket (inside or outside port)

Control function:

Intelligent weighing, automatic peeling, fast and slow feeding, drop correction, out-of-tolerance alarm, fault self-diagnosis, manual/automatic mode switch, automatic loose bag, emergency stop, communication interface

　                                             Technical parameters:

Working ability:

120～240 bag/h

Packing specifications:

10～50kg/bag

Accuracy level:

≤±0.2％(Special materials according to national or industrial standards)

Electricity source:

380/220VAC 50HZ/customize

Gas source:

pressure 0.5～0.8MPa， Air consumption 3-5ｍ3/h

Dust removal air rate:

1500~3000 m3/h

Environmental requirements:

temperature -10～40℃       humidity≤80％

Overall dimensions:

Refer to the layout

　                                                Optional device:

Sealing equipment:

Heat sealing machine, ultrasonic sealing machine, etc

Automatic transmission:

Belt conveyor

Dust removal seal:

Dust collector (reserved dust removal interface), environmental protection and dust-proof design

Safety protection:

Dustproof/waterproof, explosion-proof, electrostatic protection

Special measures:

Arch breaking and auxiliary feeding device, anti - adhesion wall bonding measures, wear - resistant anticorrosion measures

Other accessories:

High/low level palletizer or machine hand palletizer and other equipment constitute automatic packaging palletizing production line
