Automatic weighting valve bag dry mortar packing machine

Valve bag automatic weighting dry powder /mortar packing machine is very common in the product packaging of the powder industry, such as cement and dry powder mortar packaging is widely used in valve packaging machine. The feeding form of the valve packing machine has two forms of impeller feeding and air feeding, the former is suitable for the packaging of materials with relatively small particles, and the latter is more suitable for the packaging of materials with slightly viscosity and relatively large particles.

The speed of the motor is adjusted stepless by the frequency converter, and the flow rate of the material in the feeding tube is adjusted by the size of the air flow. The whole process is completed by the microcomputer. The specific method is that in the initial stage of material filling, the high-speed impeller or air will feed the material into the filling port, and the thrust formed and the compressed air located in the filling tube will help the material quickly flow into the packaging bag; When the material is filled to about 70% of the required weight, the motor begins to slow down, until the required packaging weight is reached, the auxiliary flow pressure is gradually reduced, and the section of the canning tube is gradually reduced under the action of the cylinder until the precise weighing is completely closed.
The improved valve type dry powder mortar packaging machine, due to the use of larger diameter filling pipe, speed up the initial filling speed, reduce the phenomenon of tube blocking, increase the scope of adaptation to the material, packaging speed up; The multi-stage joint control of the flow speed in the later stage can rapidly reduce the flow rate of the material and ensure the packaging accuracy. The packaging mouth is equipped with dust collection cover, which can effectively reduce dust diffusion and improve the working environment.

Dry powder mortar packaging machine is divided into impeller type dry powder mortar packing machine, air floating dry powder mortar filling machine, ultrasonic hot sealing dry powder mortar bagging machine, we will introduce these three packaging machines in detail：

I   impeller type dry powder mortar packing machine

II   air floating dry powder mortar filling machine

III   ultrasonic hot sealing dry powder mortar bagging machine

Zhengzhou Yishang Machinery Equipment Co., LTD. Production of dry mortar packing machine can pack all kinds of mortar:

Bonding mortar: such as ceramic tile binder, caulk, insulation bonding mortar, etc
Plastering mortar: such as interior and exterior putty powder, insulation plastering mortar, color decorative mortar, etc
Masonry mortar: such as ordinary masonry mortar, concrete block mortar, insulation masonry mortar, etc
Floor mortar: such as ordinary floor mortar, self-leveling mortar, etc
Special mortar: such as repair mortar, waterproof mortar, hardening powder, plaster plaster, polymer insulation anti-crack mortar, etc
